PRODUCT OVERVIEW
The Fire Alarm Bell incorporates a solenoid actuation mechanism and is designed for fire alarm applications. Its low current consumption, ease of installation incorporating diode polarity suppression and traditionally recognisable bell sound, makes it an ideal choice for fire alarm installations.
FEATURES
- Red finish with FIRE lettering
- Solenoid actuating mechanism
- Suitable for indoor use
- Back box available
SPECIFICATION
- Operating voltage : 19-27 VDC
- Operating current : 100mA
- Size (without back box) : 200mm Dia x 70mm D
- Sound level : 85 dB @ 3m
- Operating temperature : -20°C to +70°C (no icing)
- Weight : 1.25kg
ITEM NUMBER
- Bell 200mm 24Vdc : 206-0001
DOWNLOADS
Product Data Sheet
